Mobile crane LTM 1300-6.4

LTM 1300-6.4

Mobile crane

LTM 1300-6.4 - Reaching new heights.

As the successor to the LTM 1300-6.3, the LTM 1300-6.4 not only features a new crane design. It is also the third mobile crane equipped with the LICCON3 control system in the Liebherr portfolio. With its 90-metre telescopic boom, the 6-axle machine is designed for high performance at extreme lifting heights and steep boom positions. The 300-tonner is ideal for tower crane assembly and the installation of antennas, as well as wind turbine maintenance.

HVO fuel

Compare

Max. load capacity - 300 t
300 t
Telescopic boom - 90 m
90 m
Max. hoist height - 120 m
120 m
Max. radius - 94 m
94 m
Number of axles - 6
6

HVO fuel

Compare

What's inside

World record:

a 90 m / 295 ft telescopic boom that can be carried in full with an axle load of 12 t / 26,450 lb.

Variable support:

VarioBase® Plus supporting base enables the outriggers to be extended to different lengths and delivers even greater lifting capacities through its trapezoidal shape.

Economical and compact :

the mechanically adjustable VarioBallast® ballasting system enables the amount of ballast to be reduced whilst also enabling easy access to particularly constricted sites.

Flexible in the wind:

load charts with different maximum wind speeds of up to 15.6 m/s increase flexibility and safety in everyday use.

LICCON3:

The third generation of the LICCON control system takes the familiar crane control to a new level and features some impressive new technologies.

Perfectly ballasted:

the counterweight has been improved both for transport and full crane operations. AutoBallast enables the ballasting process to be completed quickly and easily.

Photo gallery

Technical data

Max. load capacity	300 t
at radius	3.00 m
Telescopic boom from	14.70 m
Telescopic boom up to	90.00 m
Lattice jib from	4.00 m
Lattice jib up to	43.00 m
Drive engine/make	Liebherr
Drive engine	8-Zylinder-Diesel
Drive engine/power	455 kW
Number of axles	6
Drive/Steering standard	12 x 6 x 12
Drive/Steering option	12 x 8 x 12
Driving speed	85.00 km/h
Total ballast	88.00 t

Downloads

Technical Data - Mobile crane LTM 1300-6.4 [m/t]

PDF (4.9 MB)

Boom/jib combinations

Driving conditions

On-road driving

Jobsite driving

Ballast systems

Counterweight

VarioBallast: Counterweight radius

Technology

ECOmode

ECOmode minimises both fuel consumption and noise emissions when operating the crane superstructure. The crane operator sets the required working speed using the control lever. The crane control system calculates the perfect engine speed for the diesel engine.

ECOdrive

ECOdrive makes the mobile crane significantly more comfortable and quieter by reducing the engine speed. Faster gearshifting delivers greater dynamic and traction offroad. On the road, the torque from the Liebherr diesel engine is used efficiently to minimise fuel consumption.

Single-engine concept

Take one engine out to increase lifting capacity. Or more accurately – the superstructure is powered by the undercarriage engine. Gear shafts are routed from the distributor gear in the substructure via two mitre gears to the pump distributor gear in the superstructure. That enables us to remove one engine – and we use this to increase the crane’s lifting capacity.

LICCON3

The third generation LICCON control system features the same time-tested operation as previous generations and adds a fast data bus, significantly more storage space and greater computing power. LICCON3 cranes are prepared for telematics and fleet management.

VarioBase® Plus

The combination of VarioBase technology and the crane’s structural steelwork. A trapezoidal support combined with the various support base delivers even higher lifting capacities, particularly over the crane’s rear outriggers.

VarioBallast® (mechanical)

Mechanically slewing ballasting cylinders enable the ballast radius to be changed quickly to two different settings. The smaller radius is used in constricted conditions whilst the larger one is used if a higher lifting capacity is required. This significantly increases the crane’s flexibility.
